PS90 Series Casement Window

Product Configuration

Frame Width: 90mm

Profile Wall Thickness: 2.2mm

Hardware Configuration: SAVIO/FRAMMAN/Wehag

Glass Configuration: 6mm+27A+6mm

Glass Configuration: 6mm+16A+5mm+16A+6mm

Sealing Rubber Strips: EPDM

Thermal Insulation Strips: 35.3mm PA66GF25

Opening Methods: Tilt & Turn / Externally Casement / Externally Top-hung


Product Configuration
Frame Width: 90mm	Profile Wall Thickness: 2.2mm
Hardware Configuration: SAVIO/FRAMMAN/Wehag	Glass Configuration: 6mm+27A+6mm
Glass Configuration: 6mm+16A+5mm+16A+6mm	Sealing Rubber Strips: EPDM
Thermal Insulation Strips: 35.3mm PA66GF25	Opening Methods: Tilt & Turn / Externally Casement / Externally Top-hung

Product Features
6060-T66 aluminum profile is adopted for superior durability and high strength	Window Frame and Sash Flush Design with No Protrusions Inside and Out
The long-tail sealing strips installed on both sides of the glass deliver enhanced airtightness	Vertical isothermal line & four-chamber energy-saving structure of the window frame
EPDM rubber strips for excellent corrosion resistance and airtightness	Automotive-grade float tempered glass for higher transparency and safety
Welded equal-pressure rubber strips for inward-opening windows, enhancing airtightness	European-Style Hardware Boasts Outstanding Aesthetics, Fashion and Durability
Pin-and-glue corner assembly for stronger structural stability and better airtightness	The Technoform nylon thermal barrier strips offer excellent heat insulation performance
Additional nylon glue blocks on the mullion to improve airtightness	Energy-saving and soundproof cotton filling available to upgrade structural performance
Optional warm-edge spacers with triple ultra-clear standard glass	Exposed drainage system with drainage caps for dust prevention and smooth water discharge
Stainless Steel R3.5 Corner Guards for Inward-opening Sashes (Safety Protection)
